Norwesco Single Wall Tanks

Single Wall Tanks

SIZE RANGE AVAILABLE FROM 25 GALLONS - 550 GALLONS

PART NO.	CAPACITY (USG)	DIAMETER	HEIGHT
41867	25	18	29
41865	50	18	53
45192	65	23	38
41863	75	23	49
41861	100	28	43
40803	105	23	63
40318	120	38	31
45870	140	25	73
41859	150	30	56
44536	160	28	69
40281	165	31	56
41856	200	30	72
47401	210	32	69
40320	220	42	44
44538	225	31	77
41854	250	30	89
40213	300	36	79
40302	305	46	50
43625	310	32	94
40148	500	48	73
40023	550	67	44

SIZE RANGE AVAILABLE FROM 750 GALLONS - 3000 GALLONS

PART NO.	CAPACITY (USG)	DIAMETER	HEIGHT
40606	750	48	103
42214	850	48	118
40152	1000	64	80
40154	1000	64	80
44818	1050	48	152
44820	1050	48	152
40070	1100	87	53
40081	1100	87	53
44968	1295	84	64
44970	1295	84	64
40144	1500	64	116
40146	1500	64	116
40235	1550	87	67
40236	1550	87	67
40010	1700	87	74
40012	1700	87	74
47109	2000	64	152
47564	2000	64	152
40178	2100	87	89
40241	2100	87	89
40051	2500	95	91
40052	2500	95	91
40754	3000	95	109
40755	3000 H	95	109
43092	3000 W/3"	95	109
43093	3000 H/W/3"	95	109

SIZE RANGE AVAILABLE FROM 4000 GALLONS - 20000 GALLONS

PART NO.	CAPACITY (USG)	DIAMETER	HEIGHT
40312	4000	102	125
41403	4200	102	131
40164	5000	102	152
40166	5000	102	152
40659	6100	119	140
40661	6100	119	140
40545	10000	141	160
40353	10000	141	160
40539	12000	141	193
40541	12000	141	193
43821	15000	165	186
43823	15000	165	186
43825	20000	165	242
43827	20000	165	242
